The Tesla Gateway 3 is the essential energy management unit for every Powerwall 3 installation. It handles automatic backup switching, load monitoring, and seamless solar integration.
Tesla Gateway 3 | Model: TSL-GTWY3 | Grid-Interface + Backup Control Panel
The Tesla Gateway 3 is a critical component for your home energy system, managing connection between your battery, solar, and the utility grid. It controls seamless transitions during grid outages, enables time-based energy usage and self-consumption of solar, and provides real-time system monitoring.
Key Features
-
Whole-home backup control: Detects grid outages and automatically switches to backup mode via your battery system.
-
High throughput capacity: 120/240 V split-phase AC, 200 A continuous current rating for robust system integration.
-
Compact installation: Dimensions are 26 × 16 × 6 in and weight is 36 lb — wall-mountable and rated for indoor/outdoor (NEMA 3R) environments.
-
Seamless monitoring: Works with the Tesla App to monitor battery, solar and home energy usage in one interface.
-
Built for reliability: Operating temperature range –4 °F to +122 °F, rated for up to 22–25 kA short-circuit current depending on breaker setup.
Specifications
| Parameter | Value |
|---|---|
| Nominal Grid Voltage | 120/240 V AC |
| Grid Frequency | 60 Hz |
| Continuous Current Rating | 200 A |
| Maximum Supply Short-Circuit Current | 22 kA (with Square D/Eaton) / 25 kA (with Eaton) |
| Dimensions | 26 × 16 × 6 in (660 × 411 × 149 mm) |
| Weight | 36 lb (16.3 kg) |
| Operating Temperature | –4 °F to +122 °F (–20 °C to +50 °C) |
| Enclosure Rating | NEMA 3R (Indoor/Outdoor) |
| Mounting | Wall-mount |
Ideal For
-
Homes equipped with Tesla Powerwall systems needing a robust gateway for grid, home and solar coordination.
-
Installations requiring whole-home backup, solar self-consumption and time-of-use energy management.
-
Environments where space is limited — compact form factor and versatile mounting make it suitable for indoor and outdoor use.
