MEGA 100 SLIM SLX | 100W Slim Solar Panel
Compact 12V Off-Grid Narrow Solar Panel for Campers, Overlanders & Boats
25-Year Output Warranty | UL Certified
Key Features
-
High-efficiency 10-busbar monocrystalline cells with up to 22.6% efficiency
-
100W output from a compact 30-cell configuration
-
3.2 mm AR-coated tempered glass for maximum sunlight capture & protection
-
Power tolerance: 0 to +5W — guarantees at least rated power
-
Performs excellently in low-light conditions (cloudy, dawn/dusk)
-
Rigorously tested for UV, thermal cycling, and humidity freeze
-
PID-resistant, double EL-inspected to prevent microcracks
-
Built tough to handle 2400 Pa wind, 5400 Pa snow, and 35 mm hail at 97 km/h
Installation
-
Anodized aluminum frame — lightweight, corrosion-resistant
-
12 pre-drilled mounting holes (Z brackets, tilt, pole, or ground mount)
-
3 ft solar connectors (12 AWG) for easy plug-and-play wiring
-
Compatible with on-grid & off-grid inverters
Warranty
-
25-Year Power Output Warranty
-
10-Year Workmanship Warranty
Built-in Components
-
IP67 waterproof junction box
-
IP67 MC4-type solar connectors
-
Pre-attached panel leads (pair) — 12 AWG, 3 ft each
Electrical Specifications
| Parameter | Value |
|---|---|
| Maximum Power (Pmax) | 100W |
| Voltage at Max Power (Vmp) | 17.3V |
| Current at Max Power (Imp) | 5.78A |
| Open Circuit Voltage (Voc) | 21.8V |
| Short Circuit Current (Isc) | 6.06A |
| Max System Voltage | 1000V DC |
| Max Series Fuse Rating | 15A |
Mechanical Details
-
Dimensions: 56.7 × 15.8 × 1.2 in
-
Weight: 13.1 lb
