Description

Description

EcoFlow OCEAN Pro 24K Hybrid Inverter

Bulk Purchase · Minimum 6 Units · Model EF-PCS-24 · 24kW Split-Phase Hybrid Inverter with 40kW Solar Input

Minimum order: 6 units (bulk purchase) · $1,999 per inverter · 6 inverters minimum order

Overview

The EcoFlow OCEAN Pro Hybrid Inverter (model EF-PCS-24) is the heart of the EcoFlow OCEAN Pro home energy system. It delivers up to 24.0kW nominal AC output on 120/240V split phase, accepts up to 40kW of solar (STC) across 8 MPPTs, and provides 205A LRA load-start capability.

Each inverter supports up to 8 OCEAN Pro Batteries (80 kWh), two inverters can run in parallel (48kW), and the built-in backup socket (SS2-50P) accepts portable generators, portable power stations and V2L-capable EVs.

This listing is for bulk purchase with a minimum order of 6 units, ideal for installers and contractors standardizing on the OCEAN Pro platform.

Key Features

24.0kW AC output · 40kW solar input · 8 MPPTs · Up to 80 kWh storage · 15-year warranty

• 24.0kW / 24.0kVA Nominal AC Output (120/240V split phase; 208Y/120V supported)
• 40kW Maximum Solar STC Input – 8 MPPTs (5kW per channel)
• 205A LRA Load-Start Capability (1s)
• Up to 8 OCEAN Pro Batteries (80 kWh) per Inverter; 2 Inverters in Parallel (48kW)
• AC Coupled and DC Coupled
• Backup Socket (SS2-50P) for Portable Generators, Power Stations and V2L EVs – up to 10kW
• Built-in IMI, PV AFCI, PV GFCI, Rapid Shutdown (APsmart/NEP/Tigo), Anti-Islanding
• UL 1741 SB, UL 3141, IEEE 1547, CA Rule 21 · System UL 9540 with OCEAN Pro Battery
• BLE, Wi-Fi, Ethernet & Cellular Connectivity · EcoFlow Mobile App
• 15-Year Warranty (per EcoFlow datasheet)

Bulk Order Details

Minimum Order 6 units (bulk purchase)
Price $1,999 per inverter
Minimum Order Value $11,994 (6 × $1,999)
Model EF-PCS-24

Specifications

Product / Model EcoFlow OCEAN Pro Hybrid Inverter · EF-PCS-24
Nominal Grid Voltage (Input & Output) 120/240V~ (split phase); 208Y/120V~, 3W (from 3Ø 4W)
Grid Type / Frequency Split phase · 60Hz (57–63Hz range)
Nominal Output Power (AC) 11.5kW | 24.0kW (datasheet ratings)
Maximum Apparent Power (AC) 11.5kVA | 24.0kVA
Max Continuous Output Current (AC) 48A | 100A
Overcurrent Protection Device 60A | 125A
Max Continuous Charge Current / Power 100A AC / 24kW (5kW per battery)
Output Power Factor 0.8 leading ~ 0.8 lagging
Efficiency Solar to Home/Grid 97.5% · Solar to Battery to Home/Grid 87%
Maximum Solar STC Input 40kW
PV DC Input Voltage Range 60 – 550V DC
PV MPPT Voltage Range 60 – 480V DC
MPPTs 8 (5kW per channel) · 16A Imp / 20A Isc per MPPT
Withstand Voltage 600V DC
Energy Scalability Up to 8 OCEAN Pro Batteries (80 kWh) per inverter
Power Scalability Up to 2 units (48kW)
Coupling AC coupled and DC coupled
Load Start Capability 205A LRA (1s)
Backup Socket SS2-50P · 120V/240V AC · 60Hz · 41.6A max continuous · 300W–10kW · portable generator, portable power station, EV with V2L
Supported Islanding Devices EcoFlow OCEAN Smart Electrical Panel, OCEAN Meter Backup Switch, OCEAN Gateway
Protections IMI, PV AFCI, PV GFCI, PV Rapid Shutdown (APsmart/NEP/Tigo), AC anti-islanding
Connectivity BLE, Wi-Fi (2.4GHz), Ethernet, Cellular (LTE/4G)
AC Metering ±1%
Safety System: UL 9540 with OCEAN Pro Battery, UL 1741 with MSA · PCS: UL 1741, UL 3141, UL 1741 SB, UL 1699B, UL 1998, IEEE 1547, IEEE 1547 (LUMA), IEEE 1547A, IEEE 1547.1, CA Rule No. 21, HECO SRD 2.0, CSA C22.2 No. 107.1:16
Emissions FCC Part 15B, 15C, 15E · ICES-003 · RSS-247
Seismic AC156, IEEE 693-2005 (high)
Operating Temperature –4°F to 140°F (–20°C to 60°C), derating above 113°F (45°C)
Environment / Enclosure Indoor and outdoor rated · NEMA 3R · IP67 (power electronics), IP54 (PCS wiring compartment)
Operating Noise @1m < 45 dB(A) typical, < 60 dB(A) maximum
Mounting Wall mount
Dimensions (H × W × D) 43.3 × 17.3 in × 216 mm depth (1100 × 440 × 216 mm)
Weight 146.6 lbs / 66.5 kg (top cover not included: 6.6 lbs / 3 kg)
Warranty 15 years

View Full Specifications (PDF)

Applications

• Whole-home backup with up to 80 kWh of OCEAN Pro battery storage
• New solar + storage installs up to 40kW of PV
• AC-coupled retrofits to existing solar systems
• Running heavy loads such as HVAC, well pumps and EV chargers (205A LRA)
• Generator, power station or V2L EV backup through the built-in socket
• Installer and contractor stock for multiple OCEAN Pro projects

Frequently Asked Questions

1. What is the minimum order quantity?
This bulk listing has a minimum order of 6 units. Orders below 6 inverters cannot be placed on this listing.

2. How much power does the inverter deliver?
The EF-PCS-24 is rated up to 24.0kW / 24.0kVA nominal AC output with a 100A maximum continuous output current, and 205A LRA load-start capability.

3. How much solar can I connect?
Up to 40kW of solar (STC) across 8 MPPTs at 5kW per channel, with a 60–550V DC PV input range.

4. How many batteries does it support?
Up to 8 EcoFlow OCEAN Pro Batteries (EF-BP-10), for 80 kWh per inverter. Two inverters can be paralleled for 48kW.

5. Can I connect a generator or EV?
Yes. The SS2-50P backup socket accepts portable generators (120V or 240V), portable power stations and EVs with V2L, from 300W up to 10kW.

6. Does it work with existing solar?
It supports both AC-coupled and DC-coupled configurations.

7. What is the warranty?
The EcoFlow datasheet lists a 15-year warranty for the OCEAN Pro Hybrid Inverter.

8. Is professional installation required?
Yes. Installation should be performed by a qualified, licensed installer following local electrical codes and utility interconnection rules.
