Key Features
- 10BB Half-cut Cell Technology – New circuit design, lower internal current & Rs loss
- Ga-doped Wafer – Attenuation <2% (1st year) / ≤0.55% (linear)
- Bifacial PERC Technology – Up to 25% rear-side power gain (5%–25% more yield)
- Excellent Anti-PID – 2x industry standard (TÜV SÜD certified)
- IP68 Junction Box – High waterproof rating
- Lower LCOE – 2% more power generation than conventional modules
Electrical Data (STC)
- Maximum Power (Pmax): 415W
- Open-Circuit Voltage (Voc): 37.75V
- Short-Circuit Current (Isc): 14.02A
- Voltage at Maximum Power (Vmpp): 31.64V
- Current at Maximum Power (Impp): 13.13A
- Module Efficiency: 21.25%
Electrical Data (NMOT)
- Maximum Power (Pmax): 310W
- Open-Circuit Voltage (Voc): 35.50V
- Short-Circuit Current (Isc): 11.30A
- Voltage at Maximum Power (Vmpp): 29.60V
- Current at Maximum Power (Impp): 10.48A
Rear Side Power Gain (Reference to 410W Front)
| Gain | Pmax (W) | Vmpp (V) | Impp (A) | Voc (V) | Isc (A) |
|---|---|---|---|---|---|
| 5% | 431 | 31.43 | 13.70 | 37.50 | 14.65 |
| 10% | 451 | 31.43 | 14.36 | 37.50 | 15.35 |
| 15% | 472 | 31.43 | 15.01 | 37.50 | 16.04 |
| 20% | 492 | 31.43 | 15.66 | 37.50 | 16.74 |
| 25% | 513 | 31.43 | 16.31 | 37.50 | 17.44 |
Mechanical Characteristics
- Solar Cell: Monocrystalline 182×182mm
- No. of Cells: 108 (6×18)
- Dimensions: 1722 × 1134 × 30 mm (67.80 × 44.65 × 1.18 in)
- Weight: 21.5 kg (47.4 lbs)
- Front Glass: 3.2mm AR-coated tempered glass
- Frame: Anodized aluminum alloy
- Junction Box: IP68, 3 bypass diodes
- Connectors: T01/LJQ-3-CSY / MC4 / MC4-EVO2
- Cables: 4mm² (IEC), 12 AWG (UL), 350mm(+)/250mm(-) or custom length
- Bifaciality Factor: 70% ±5% / -10%
Temperature Characteristics
- Pmax: -0.35%/°C
- Voc: -0.26%/°C
- Isc: +0.048%/°C
- NMOT: 43 ± 2°C
Application Conditions
- Max System Voltage: 1000V / 1500V DC
- Operating Temperature: -40°C to +85°C
- Max Series Fuse: 30A
- Safety Class: Class II
- Mechanical Load: Front 5400Pa / Back 2400Pa
Performance Warranty
- 25-Year Product Warranty
- 25-Year Linear Power Warranty
- 1st Year: ≥98%
- After 25 Years: ≥84.8%
Packing Configuration
- Pieces per Pallet: 36
- Pieces per 40'HQ Container: 936 (828 USA)
Certifications
- IEC 61215 / IEC 61730 / UL 61730
- ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
STC: 1000W/m², AM1.5, 25°C | NMOT: 800W/m², AM1.5, 20°C ambient, 1m/s wind Power tolerance: 0~+5W | Test uncertainty for Pmax: ±3%
Ideal for commercial & utility-scale projects – Maximize energy harvest with bifacial gain and proven long-term reliability.
